Inverters

Details Take control of your home's energy with the GivEnergy string inverter. It's designed for single-phase systems such as residential properties and small businesses, while its attractive design means it looks great wherever you position it. String inverters take the energy generated by your solar panel system and convert it to AC power for use in your property. By connecting it to Wi-Fi or LAN, you can manage your energy usage through the cloud portal or app, and receive over-the-air firmware updates. Key features: String inverter designed for single-phase systems Two MPPTs with one string each Manage your home energy via the GivEnergy cloud portal and mobile app Over-the-air firmware updates Inbuilt Wi-Fi and LAN connectivity Arc fault circuit interrupter PV maximum efficiency: 97.6% Ingress protection: IP65 Startup voltage: 80V Nominal voltage: 360V Dimensions: 480mm (W) x 583mm (H) x 205mm (D) Weight: 32kg 12-year warranty

Read more less

Details Take control of your home's energy with the GivEnergy string inverter. It's designed for single-phase systems such as residential properties and small businesses, while its attractive design means it looks great wherever you position it. String inverters take the energy generated by your solar panel system and convert it to AC power for use in your property. By connecting it to Wi-Fi or LAN, you can manage your energy usage through the cloud portal or app, and receive over-the-air firmware updates. Key features: String inverter designed for single-phase systems Two MPPTs with one string each Manage your home energy via the GivEnergy cloud portal and mobile app Over-the-air firmware updates Inbuilt Wi-Fi and LAN connectivity Arc fault circuit interrupter PV maximum efficiency: 97.6% Ingress protection: IP65 Startup voltage: 80V Nominal voltage: 360V Dimensions: 480mm (W) x 583mm (H) x 205mm (D) Weight: 32kg 12-year warranty

Read more less

GivEnergy design and manufacture their own inverters, batteries and state-of-the-art management system and monitoring platform which combine to offer an exceptional storage package. This AC coupled 3kW unit will charge from surplus PV generation, and also from the grid if you're on an economy tariff. Wi-fi comes as standard and gives access to the powerful monitoring platform, along with remote, site-specific firmware upgrades and troubleshooting via web browser or app. GivEnergy hybrid systems provide backup power of up to 2.5kW to dedicated critical circuits, where output depends on battery capacity. These circuits require an isolator or change over switch which is recommended to be rated to 20A or greater.

Read more less

Data Sheet - Click Here  Quick Installation Manual - Click Here  PV Input Max. PV array power : 6180Wp Max. input voltage : 550V MPPT voltage range / rated input voltage : 40V to 530V/380V Min. input voltage / start voltage : 40V/50V No. of independent MPPT trackers / strings per MPPT input : 2 / 1 Max. input current per MPP tracker : 16A Max. short-circuit current per MPP tracker : 20A Battery Input Nominal battery voltage : 48V/51.2V Battery voltage range : 40V to 60V Max. charging / discharge power : 5000W/5000W Max. charging current / Max. discharging current : 100A/100A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 180V to 280V/230V Rated AC grid frequency : 50Hz / 60Hz Rated apparent power : 3680VA Max. apparent power : 3680VA Rated grid output current (@230V) : 16A Max. grid output current : 16A AC Input Rated grid voltage : a.c.230V Rated apparent power : 6000VA Max. input apparent power from grid : 6000VA Rated input curent from grid : a.c.26.1 A Max. input current from grid : a.c.27.3 A EPS Output Nominal output voltage : 230V Nominal output frequency : 50 Hz/ 60Hz Rated apparent power : 5000VA Max. output apparent power : 5000VA Peak output apparent power : 7500 VA | 10s Max. output current : 21.7A Max. switch time : ≤10ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : 97%/97.6% Max. battery to load efficiency : 94.70% General Data Dimensions (W*H*D) (mm) : 483*455*193.5 Device weight : 25.1Kg Operating temperature range : -25℃ ~60℃ Noise emissions (typical) : 30 dB(A) Standby consumption : ＜10 W Degree of protection (as per lEC 60529) : IP66 Features User interface : LED & APP Communication with BMS : RS485 / CAN Communication with meter : RS485 Communication with portal : WiFi/LAN/4G/Bluetooth Other communication : DRM Communication : / Integrated power control / Zero export control : Integrated/Integrated Certifications : EN 61000/IEC 62109/EN 50549/G98/G99/G100/VDE 4105/VFR 2019/NRS 097/CEI 0-21/NTS/IEC 61683/IEC 61727/IEC 62116 Warranty : 12 years

Read more less

Data Sheet - Click Here  Quick Installation Manual - Click Here  PV Input Max. PV array power : 7500Wp Max. input voltage : 550V MPPT voltage range / rated input voltage : 40V to 530V/380V Min. input voltage / start voltage : 40V/50V No. of independent MPPT trackers / strings per MPPT input : 2 / 1 Max. input current per MPP tracker : 16A Max. short-circuit current per MPP tracker : 20A Battery Input Nominal battery voltage : 48V/51.2V Battery voltage range : 40V to 60V Max. charging / discharge power : 5000W/5000W Max. charging current / Max. discharging current : 100A/100A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 180V to 280V/230V Rated AC grid frequency : 50Hz / 60Hz Rated apparent power : 5000VA Max. apparent power : 5000VA Rated grid output current (@230V) : 21.7A Max. grid output current : 22.7A AC Input Rated grid voltage : a.c.230V Rated apparent power : 6000VA Max. input apparent power from grid : 6000VA Rated input curent from grid : a.c.26.1 A Max. input current from grid : a.c.27.3 A EPS Output Nominal output voltage : 230V Nominal output frequency : 50 Hz/ 60Hz Rated apparent power : 5000VA Max. output apparent power : 5000VA Peak output apparent power : 7500 VA | 10s Max. output current : 21.7A Max. switch time : ≤10ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : 97%/97.6% Max. battery to load efficiency : 94.70% General Data Dimensions (W*H*D) (mm) : 483*455*193.5 Device weight : 25.1Kg Operating temperature range : -25℃ ~60℃ Noise emissions (typical) : 30 dB(A) Standby consumption : ＜10 W Degree of protection (as per lEC 60529) : IP66 Features User interface : LED & APP Communication with BMS : RS485 / CAN Communication with meter : RS485 Communication with portal : WiFi/LAN/4G/Bluetooth Other communication : DRM Communication : / Integrated power control / Zero export control : Integrated/Integrated Certifications : EN 61000/IEC 62109/EN 50549/G98/G99/G100/VDE 4105/VFR 2019/NRS 097/CEI 0-21/NTS/IEC 61683/IEC 61727/IEC 62116 Warranty : 12 years

Read more less

Data Sheet - Click Here  Quick Installation Manual - Click Here  PV Input Max. PV array power : 9000Wp Max. input voltage : 550V MPPT voltage range / rated input voltage : 40V to 530V/380V Min. input voltage / start voltage : 40V/50V No. of independent MPPT trackers / strings per MPPT input : 2 / 1 Max. input current per MPP tracker : 16A Max. short-circuit current per MPP tracker : 20A Battery Input Nominal battery voltage : 48V/51.2V Battery voltage range : 40V to 60V Max. charging / discharge power : 5000W/5000W Max. charging current / Max. discharging current : 100A/100A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 180V to 280V/230V Rated AC grid frequency : 50Hz / 60Hz Rated apparent power : 6000VA Max. apparent power : 6000VA Rated grid output current (@230V) : 26.1A Max. grid output current : 27.3A AC Input Rated grid voltage : a.c.230V Rated apparent power : 6000VA Max. input apparent power from grid : 6000VA Rated input curent from grid : a.c.26.1 A Max. input current from grid : a.c.27.3 A EPS Output Nominal output voltage : 230V Nominal output frequency : 50 Hz/ 60Hz Rated apparent power : 5000VA Max. output apparent power : 5000VA Peak output apparent power : 7500 VA | 10s Max. output current : 21.7A Max. switch time : ≤10ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : 97%/97.6% Max. battery to load efficiency : 94.70% General Data Dimensions (W*H*D) (mm) : 483*455*193.5 Device weight : 25.1Kg Operating temperature range : -25℃ ~60℃ Noise emissions (typical) : 30 dB(A) Standby consumption : ＜10 W Degree of protection (as per lEC 60529) : IP66 Features User interface : LED & APP Communication with BMS : RS485 / CAN Communication with meter : RS485 Communication with portal : WiFi/LAN/4G/Bluetooth Other communication : DRM Communication : / Integrated power control / Zero export control : Integrated/Integrated Certifications : EN 61000/IEC 62109/EN 50549/G98/G99/G100/VDE 4105/VFR 2019/NRS 097/CEI 0-21/NTS/IEC 61683/IEC 61727/IEC 62116 Warranty : 12 years

Read more less

Installation Guide - Click Here  Data Sheet - Click Here  PV Input Max. PV array power : 9000Wp Max. input voltage : 1100V MPPT voltage range / rated input voltage : 150V to 950V/630V Min. input voltage / start voltage : 60V/180V No. of independent MPPT trackers / strings per MPPT input : 2 / 1 Max. input current per MPP tracker : 20A Max. short-circuit current per MPP tracker : 30A Battery Input Nominal battery voltage : / Battery voltage range : 120V to 600V Max. charging / discharge power : 6000W Max. charging current / Max. discharging current : 36A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 270V to 480V /3/N/PE | 220/380V; 230/400V;240/415V Rated AC grid frequency : 50Hz/ 60Hz Rated apparent power : 6000VA Max. apparent power : 6000VA Rated grid output current (@230V) : 8.7A Max. grid output current : 9.6A AC Input Rated grid voltage : 3/N/PE | 220/380V;230/400V;240/415V Rated apparent power : 12000W Max. input apparent power from grid : / Rated input curent from grid : / Max. input current from grid : 17.4A EPS Output Nominal output voltage : 3/N/PE | 220/380V;230/400V;240/415V Nominal output frequency : 50Hz/ 60Hz Rated apparent power : 6000VA Max. output apparent power : / Peak output apparent power : 2 times of rated power | 10s Max. output current : 8.7A Max. switch time : ＜10ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : 97.5%/98.2% Max. battery to load efficiency : / General Data Dimensions (W*H*D) (mm) : 545*465*205 Device weight : 24.5Kg Operating temperature range : -25℃~+60℃ Noise emissions (typical) : / Standby consumption : / Degree of protection (as per lEC 60529) : IP66 Features User interface : LED & APP Communication with BMS : CAN Communication with meter : RS485 Communication with portal : WiFi/LAN/5G/Bluetooth Other communication : / Communication : / Integrated power control / Zero export control : Integrated/Integrated Certifications : EN 61000/IEC 62109/EN 50549/VDE 4105/VFR 201/ G98/G99/G100/CEI 0-21/NEN Warranty : 12 years

Read more less

Installation Guide - Click Here  Data Sheet - Click Here  PV Input Max. PV array power : 12000Wp Max. input voltage : 1100V MPPT voltage range / rated input voltage : 200V to 950V/630V Min. input voltage / start voltage : 60V/180V No. of independent MPPT trackers / strings per MPPT input : 2 / 1 Max. input current per MPP tracker : 20A Max. short-circuit current per MPP tracker : 30A Battery Input Nominal battery voltage : / Battery voltage range : 120V to 600V Max. charging / discharge power : 8000W Max. charging current / Max. discharging current : 36A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 270V to 480V /3/N/PE | 220/380V; 230/400V;240/415V Rated AC grid frequency : 50Hz/ 60Hz Rated apparent power : 8000VA Max. apparent power : 8000VA Rated grid output current (@230V) : 11.6A Max. grid output current : 12.8A AC Input Rated grid voltage : 3/N/PE | 220/380V;230/400V;240/415V Rated apparent power : 16000W Max. input apparent power from grid : / Rated input curent from grid : / Max. input current from grid : 23.2A EPS Output Nominal output voltage : 3/N/PE | 220/380V;230/400V;240/415V Nominal output frequency : 50Hz/ 60Hz Rated apparent power : 8000VA Max. output apparent power : / Peak output apparent power : 2 times of rated power | 10s Max. output current : 11.6A Max. switch time : ＜10ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : 97.9%/98.4% Max. battery to load efficiency : / General Data Dimensions (W*H*D) (mm) : 545*465*205 Device weight : 24.5Kg Operating temperature range : -25℃~+60℃ Noise emissions (typical) : / Standby consumption : / Degree of protection (as per lEC 60529) : IP66 Features User interface : LED & APP Communication with BMS : CAN Communication with meter : RS485 Communication with portal : WiFi/LAN/5G/Bluetooth Other communication : / Communication : / Integrated power control / Zero export control : Integrated/Integrated Certifications : EN 61000/IEC 62109/EN 50549/VDE 4105/VFR 201/ G98/G99/G100/CEI 0-21/NEN Warranty : 12 years

Read more less

GivEnergy design and manufacture their own inverters, batteries and state-of-the-art management system and monitoring platform which combine to offer an exceptional storage package. The third generation of the GivEnergy Hybrid inverter is a DC-coupled storage solution which allows you to seemlessly integrate battery storage into PV systems.  The Givenergy Gen 3 hybrid inverter offers all of the benefits of the Givenergy Gen 2 hybrid inverter while benefiting from a cleaner design discretely enclosing the connection ports. Additionally, the Gen 3 has an increased max input current per string of 15A allowing for higher current panels to be utilised in your system designs and an increased MPPT range. Inbuilt WiFi and LAN: Includes in-built WiFi and LAN for a hard-wired network connection. Higher Charge/Discharge Rate: High efficiency, high battery discharge rates of up to 3.6kW. Flexible Rate Tariff: Charge the battery off peak where its cleaner, greener and less costly, then discharge the battery during peak times for maximum saving. 12 Year Warranty: Supplied with a full manufacturers warranty. GivEnergy's UK team are on hand to help you should any issues arise. Installers must now offer an SPD to the homeowner for them to decide whether they would like one installed. Giv inverters do not come with an SPD inbuilt which means that installers will need to offer their own. Key features In-built WiFi and LAN for internet connectivity. Backup for power cuts with 10ms automatic switch time. 12 year warranty* when commissioned online by a certified GivEnergy installer.

Read more less

GivEnergy design and manufacture their own inverters, batteries and state-of-the-art management system and monitoring platform which combine to offer an exceptional storage package. The third generation of the GivEnergy Hybrid inverter is a DC-coupled storage solution which allows you to seamlessly integrate battery storage into PV systems. The GivEnergy Gen 3 hybrid inverter offers all of the benefits of the GivEnergy Gen 2 hybrid inverter while benefiting from a cleaner design discretely enclosing the connection ports. The 5kW Gen 3 hybrid inverter comes with an increased backup power output capability of 5kW when Solar and Battery are used in tandem. Additionally, the Gen 3 has an increased max input current per string of 15A allowing for higher current panels to be utilised in your system designs and an increased MPPT range.  Inbuilt WiFi and LAN: Includes in-built WiFi and LAN for a hard-wired network connection. Higher Charge/Discharge Rate: High efficiency, high battery discharge rates of up to 3.6kW. Flexible Rate Tariff: Charge the battery off peak where its cleaner, greener and less costly, then discharge the battery during peak times for maximum saving. 12 Year Warranty: Supplied with a full manufacturers warranty, extendable to 10 years. GivEnergy's UK team are on hand to help you should any issues arise. Installers must now offer an SPD to the homeowner for them to decide whether they would like one installed. Giv inverters do not come with an SPD inbuilt which means that installers will need to offer their own. Key features In-built WiFi and LAN for internet connectivity.Backup for power cuts with 10ms automatic switch time.12 year warranty* when commissioned online by a certified GivEnergy installer.

Read more less

Installation Guide - Click Here  Data Sheet - Click Here  PV Input Max. PV array power : 15000Wp Max. input voltage : 1100V MPPT voltage range / rated input voltage : 200V to 950V/630V Min. input voltage / start voltage : 60V/180V No. of independent MPPT trackers / strings per MPPT input : 2 / 1 Max. input current per MPP tracker : 20A Max. short-circuit current per MPP tracker : 30A Battery Input Nominal battery voltage : / Battery voltage range : 120V to 600V Max. charging / discharge power : 10000W Max. charging current / Max. discharging current : 36A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 270V to 480V /3/N/PE | 220/380V; 230/400V;240/415V Rated AC grid frequency : 50Hz/ 60Hz Rated apparent power : 10000VA Max. apparent power : 10000VA Rated grid output current (@230V) : 14.5A Max. grid output current : 16A AC Input Rated grid voltage : 3/N/PE | 220/380V;230/400V;240/415V Rated apparent power : 20000W Max. input apparent power from grid : / Rated input curent from grid : / Max. input current from grid : 29.0A EPS Output Nominal output voltage : 3/N/PE | 220/380V;230/400V;240/415V Nominal output frequency : 50Hz/ 60Hz Rated apparent power : 10000VA Max. output apparent power : / Peak output apparent power : 2 times of rated power | 10s Max. output current : 14.5A Max. switch time : ＜10ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : 97.9%/98.4% Max. battery to load efficiency : / General Data Dimensions (W*H*D) (mm) : 545*465*205 Device weight : 24.5Kg Operating temperature range : -25℃~+60℃ Noise emissions (typical) : / Standby consumption : / Degree of protection (as per lEC 60529) : IP66 Features User interface : LED & APP Communication with BMS : CAN Communication with meter : RS485 Communication with portal : WiFi/LAN/5G/Bluetooth Other communication : / Communication : / Integrated power control / Zero export control : Integrated/Integrated Certifications : EN 61000/IEC 62109/EN 50549/VDE 4105/VFR 201/ G98/G99/G100/CEI 0-21/NEN Warranty : 12 years

Read more less

Installation Guide - Click Here  Data Sheet - Click Here  PV Input Max. PV array power : 18000Wp Max. input voltage : 1100V MPPT voltage range / rated input voltage : 200V to 950V/630V Min. input voltage / start voltage : 60V/180V No. of independent MPPT trackers / strings per MPPT input : 2 / 1 Max. input current per MPP tracker : 20A Max. short-circuit current per MPP tracker : 30A Battery Input Nominal battery voltage : / Battery voltage range : 120V to 600V Max. charging / discharge power : 12000W Max. charging current / Max. discharging current : 36A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 270V to 480V /3/N/PE | 220/380V; 230/400V;240/415V Rated AC grid frequency : 50Hz/ 60Hz Rated apparent power : 12000VA Max. apparent power : 12000VA Rated grid output current (@230V) : 17.4A Max. grid output current : 19.2A AC Input Rated grid voltage : 3/N/PE | 220/380V;230/400V;240/415V Rated apparent power : 24000W Max. input apparent power from grid : / Rated input curent from grid : / Max. input current from grid : 34.8A EPS Output Nominal output voltage : 3/N/PE | 220/380V;230/400V;240/415V Nominal output frequency : 50Hz/ 60Hz Rated apparent power : 12000VA Max. output apparent power : / Peak output apparent power : 2 times of rated power | 10s Max. output current : 17.4A Max. switch time : ＜10ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : 97.9%/98.4% Max. battery to load efficiency : / General Data Dimensions (W*H*D) (mm) : 545*465*205 Device weight : 24.5Kg Operating temperature range : -25℃~+60℃ Noise emissions (typical) : / Standby consumption : / Degree of protection (as per lEC 60529) : IP66 Features User interface : LED & APP Communication with BMS : CAN Communication with meter : RS485 Communication with portal : WiFi/LAN/5G/Bluetooth Other communication : / Communication : / Integrated power control / Zero export control : Integrated/Integrated Certifications : EN 61000/IEC 62109/EN 50549/VDE 4105/VFR 201/ G98/G99/G100/CEI 0-21/NEN Warranty : 12 years

Read more less

Details Powerful and versatile, the GivEnergy 11kW three-phase hybrid inverter combines both a battery inverter and a solar inverter in one unit. This allows for easy and efficient use of both solar panels and energy storage to generate and store electricity for later use in your chosen battery. The inverter is AC- and DC-coupled, making it incredibly flexible and easy to install. It also features on/off grid phase balancing, which ensures that power is distributed evenly between the grid and the battery. One of the key benefits of the GivEnergy three-phase inverter is its increased efficiency. It can deliver higher discharge rates, up to 11kW for this model, which means it's able to store and distribute more energy than other similar inverters on the market. This makes it an ideal choice for anyone looking to maximise their energy savings and reduce their carbon footprint. The inbuilt Wi-Fi network connection allows for easy monitoring and control of the system, so you can always keep track of your energy usage and make adjustments as needed. The unit is also compatible with the GivEnergy battery range, making it a seamless addition to any existing energy storage setup. Key features Ultra-efficient hybrid inverter with high output power High discharge rates of up to 11kW Integrated Wi-Fi means no dongle is required Cloud-based monitoring and control through easy-to-use app Can be remotely updated via Wi-Fi Up to 11kW backup power capability Two MPPT PV inputs that allow you to have solar panels in two different orientations Dimensions: 658mm (H) x 214mm (D) x 480mm (W) Weight: 35kg Rated IP65 for ingress protection 12-year warranty

Read more less

Installation Guide - Click Here  Data Sheet - Click Here PV Input Max. PV array power : 22.5kW Max. input voltage : 1000V MPPT voltage range / rated input voltage : 200-950V Min. input voltage / start voltage : 135V No. of independent MPPT trackers / strings per MPPT input : 2 Max. input current per MPP tracker : 30*2A Max. short-circuit current per MPP tracker : 40*2A Battery Input Nominal battery voltage : / Battery voltage range : 135-750V Max. charging / discharge power : 15000W Max. charging current / Max. discharging current : 40A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated AC grid frequency : 50Hz/ 60Hz Rated apparent power : 15kW Max. apparent power : 16.5kVA Rated grid output current (@230V) : 21.7A Max. grid output current : 25A AC Input Rated grid voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated apparent power : / Max. input apparent power from grid : 30.0kVA Rated input curent from grid : / Max. input current from grid : / EPS Output Nominal output voltage : 3L/N/PE;220/380V;230/400V;240/415V Nominal output frequency : 50Hz/ 60Hz Rated apparent power : 15kW Max. output apparent power : 16.5kVA Peak output apparent power : 22.5kVA | 60s Max. output current : 25A Max. switch time : <10ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : 98.4%/97.5% Max. battery to load efficiency : / General Data Dimensions (W*H*D) (mm) : 534*418*210 Device weight : 31kg Operating temperature range : -30C ~+60C Noise emissions (typical) : <40dB Standby consumption : <15W Degree of protection (as per lEC 60529) : IP65 Features User interface : OLED&LED Communication with BMS : CAN Communication with meter : RS485 Communication with portal : WiFi/LAN Other communication : / Communication : CAN/RS485/WiFi/LAN (OPTIONAL) Integrated power control / Zero export control : Integrated/Integrated Certifications : IEC 62109/EN 61000/EN50549-1/G98/G99/G100/CEI/NRS 097/NTS/VDE-4105/CEI 0-21/NEN Warranty : 12 years

Read more less

Details Powerful and versatile, the GivEnergy 20kW three-phase hybrid inverter combines both a battery inverter and a solar inverter in one unit. This allows for easy and efficient use of both solar panels and energy storage to generate and store electricity for later use in your chosen battery. The inverter is AC- and DC-coupled, making it incredibly flexible and easy to install. It also features on/off grid phase balancing, which ensures that power is distributed evenly between the grid and the battery. One of the key benefits of the GivEnergy hybrid inverter is its increased efficiency. It can deliver higher discharge rates, up to 20kW for this model, which means it's able to store and distribute more energy than other similar inverters on the market. This makes it an ideal choice for anyone looking to maximise their energy savings and reduce their carbon footprint. The inbuilt Wi-Fi network connection allows for easy monitoring and control of the system, so you can always keep track of your energy usage and make adjustments as needed. The unit is also compatible with the GivEnergy battery range, making it a seamless addition to any existing energy storage setup. Key features Ultra-efficient hybrid inverter with high output power High discharge rates of up to 20kW Integrated Wi-Fi means no dongle is required Cloud-based monitoring and control through easy-to-use app Can be remotely updated via Wi-Fi Up to 20kW backup power capability Two MPPT PV inputs that allow you to have solar panels in two different orientations Dimensions: 658mm (H) x 214mm (D) x 480mm (W) Weight: 40.4kg Rated IP65 for ingress protection 12-year warranty

Read more less

Installation Guide - Click Here  Data Sheet - Click Here PV Input Max. PV array power : 30.0kW Max. input voltage : 1000V MPPT voltage range / rated input voltage : 200-950V Min. input voltage / start voltage : 135V No. of independent MPPT trackers / strings per MPPT input : 2 Max. input current per MPP tracker : 30*2A Max. short-circuit current per MPP tracker : 40*2A Battery Input Nominal battery voltage : / Battery voltage range : 135-750V Max. charging / discharge power : 20000W Max. charging current / Max. discharging current : 40A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated AC grid frequency : 50Hz/ 60Hz Rated apparent power : 20kW Max. apparent power : 22kVA Rated grid output current (@230V) : 29A Max. grid output current : 33.5A AC Input Rated grid voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated apparent power : / Max. input apparent power from grid : 30.0kVA Rated input curent from grid : / Max. input current from grid : / EPS Output Nominal output voltage : 3L/N/PE;220/380V;230/400V;240/415V Nominal output frequency : 50Hz/ 60Hz Rated apparent power : 20kW Max. output apparent power : 22kVA Peak output apparent power : 30kVA | 60s Max. output current : 33.5A Max. switch time : <10ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : /98.4%97.5% Max. battery to load efficiency : / General Data Dimensions (W*H*D) (mm) : 534*418*210 Device weight : 31kg Operating temperature range : -30C ~+60C Noise emissions (typical) : <40dB Standby consumption : <15W Degree of protection (as per lEC 60529) : IP65 Features User interface : OLED&LED Communication with BMS : CAN Communication with meter : RS485 Communication with portal : WiFi/LAN Other communication : / Communication : CAN/RS485/WiFi/LAN (OPTIONAL) Integrated power control / Zero export control : Integrated/Integrated Certifications : IEC 62109/EN 61000/EN50549-1/G98/G99/G100/CEI/NRS 097/NTS/VDE-4105/CEI 0-21/NEN Warranty : 12 years

Read more less

Installation Guide - Click Here  Data Sheet - Click Here  Outdoor Requirements - Click Here  Achieves up to 98.8% peak efficiency, maximising the conversion of generated energy into usable power and significantly reducing energy costs. Supports up to 110% AC output overloading and up to 120% back-up output overloading for 60 seconds, ensuring reliable performance even during peak demand. Equipped with 4 MPPTs, enabling optimal solar energy capture across multiple roof orientations and shading conditions to maximise overall solar utilization. With EPS switching time of less than 20 milliseconds, it ensures continuity of critical operations without interruption during power outages.Offers built-in surge protection, insulation resistance monitoring, and multi-layered safeguards against over-temperature and residual currents, ensuring protection for both the equipment and the premises. Easily manage settings and monitor performance via the iESS and Hanchu app, offering convenience and real-time control. The horizontal design and quick plug-in terminals enable fast and convenient installation, minimising labour time and reducing complexity. PV Input Max. PV array power : 37.5kW Max. input voltage : 1000V MPPT voltage range / rated input voltage : 200-850V Min. input voltage / start voltage : 135V No. of independent MPPT trackers / strings per MPPT input : 4 Max. input current per MPP tracker : 30A Max. short-circuit current per MPP tracker : 40A Battery Input Nominal battery voltage : / Battery voltage range : 135-750V Max. charging / discharge power : 25000W Max. charging current / Max. discharging current : 100A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated AC grid frequency : 50Hz/ 60Hz Rated apparent power : 25.0kW Max. apparent power : 27.0kVA Rated grid output current (@230V) : / Max. grid output current : 42.0A AC Input Rated grid voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated apparent power : 25.0kW Max. input apparent power from grid : 30.0kVA Rated input curent from grid : / Max. input current from grid : / EPS Output Nominal output voltage : 3L/N/PE;220/380V;230/400V;240/415V Nominal output frequency : 50Hz/ 60Hz Rated apparent power : 25.0kW Max. output apparent power : 27.5kVA Peak output apparent power : 30kVA | 60s Max. output current : 42.0A Max. switch time : ＜20ms Efficiency MPPT efficiency : 98.80% Euro efficiency / Max. efficiency : 98.30% Max. battery to load efficiency : / General Data Dimensions (W*H*D) (mm) : 800*620*300 Device weight : 76.0Kg Operating temperature range : -30℃~+60℃ Noise emissions (typical) : ＜50dB Standby consumption : ＜15W Degree of protection (as per lEC 60529) : IP65 Features User interface : OLED&LED&APP Communication with BMS : / Communication with meter : / Communication with portal : / Other communication : / Communication : RS485/CAN/WiFi/LAN(Optional) Integrated power control / Zero export control : Integrated/Integrated Certifications : IEC 62109/EN 61000/EN 50549-1/NTS/VDE-4105/G99/G100/CEI/NRS 097/CEI 0-21/NEN Warranty : 12 years

Read more less

Installation Guide - Click Here  Data Sheet - Click Here  Outdoor Requirements - Click Here  Achieves up to 98.8% peak efficiency, maximising the conversion of generated energy into usable power and significantly reducing energy costs. Supports up to 110% AC output overloading and up to 120% back-up output overloading for 60 seconds, ensuring reliable performance even during peak demand. Equipped with 4 MPPTs, enabling optimal solar energy capture across multiple roof orientations and shading conditions to maximise overall solar utilization. With EPS switching time of less than 20 milliseconds, it ensures continuity of critical operations without interruption during power outages.Offers built-in surge protection, insulation resistance monitoring, and multi-layered safeguards against over-temperature and residual currents, ensuring protection for both the equipment and the premises. Easily manage settings and monitor performance via the iESS and Hanchu app, offering convenience and real-time control. The horizontal design and quick plug-in terminals enable fast and convenient installation, minimising labour time and reducing complexity. PV Input Max. PV array power : 54.0kW Max. input voltage : 1000V MPPT voltage range / rated input voltage : 200-850V Min. input voltage / start voltage : 135V No. of independent MPPT trackers / strings per MPPT input : 4 Max. input current per MPP tracker : 30A Max. short-circuit current per MPP tracker : 40A Battery Input Nominal battery voltage : / Battery voltage range : 135-750V Max. charging / discharge power : 36000W Max. charging current / Max. discharging current : 100A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated AC grid frequency : 50Hz/ 60Hz Rated apparent power : 36.0kW Max. apparent power : 39.6kVA Rated grid output current (@230V) : / Max. grid output current : 60.0A AC Input Rated grid voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated apparent power : 36.0kW Max. input apparent power from grid : 43.5kVA Rated input curent from grid : / Max. input current from grid : / EPS Output Nominal output voltage : 3L/N/PE;220/380V;230/400V;240/415V Nominal output frequency : 50Hz/ 60Hz Rated apparent power : 36.0kW Max. output apparent power : 39.6kVA Peak output apparent power : 43.5kVA | 60S Max. output current : 60.0A Max. switch time : <20ms Efficiency MPPT efficiency : 99.90% Euro efficiency / Max. efficiency : 98.8%/98.3% Max. battery to load efficiency : / General Data Dimensions (W*H*D) (mm) : 800*620*300 Device weight : 76.0Kg Operating temperature range : -30C ~+60C Noise emissions (typical) : <50dB Standby consumption : <15W Degree of protection (as per lEC 60529) : IP65 Features User interface : OLED&LED&APP Communication with BMS : / Communication with meter : / Communication with portal : / Other communication : / Communication : RS485/CAN/WiFi/LAN(Optional) Integrated power control / Zero export control : Integrated/Integrated Certifications : IEC 62109/EN 61000/EN 50549-1/NTS/VDE-4105/G99/G100/CEI/NRS 097/CEI 0-21/NEN Warranty : 12 years

Read more less

Installation Guide - Click Here  Data Sheet - Click Here  Outdoor Requirements - Click Here  Achieves up to 98.8% peak efficiency, maximising the conversion of generated energy into usable power and significantly reducing energy costs. Supports up to 110% AC output overloading and up to 120% back-up output overloading for 60 seconds, ensuring reliable performance even during peak demand. Equipped with 4 MPPTs, enabling optimal solar energy capture across multiple roof orientations and shading conditions to maximise overall solar utilization. With EPS switching time of less than 20 milliseconds, it ensures continuity of critical operations without interruption during power outages.Offers built-in surge protection, insulation resistance monitoring, and multi-layered safeguards against over-temperature and residual currents, ensuring protection for both the equipment and the premises. Easily manage settings and monitor performance via the iESS and Hanchu app, offering convenience and real-time control. The horizontal design and quick plug-in terminals enable fast and convenient installation, minimising labour time and reducing complexity. PV Input Max. PV array power : 75.0kW Max. input voltage : 1000V MPPT voltage range / rated input voltage : 200-850V Min. input voltage / start voltage : 135V No. of independent MPPT trackers / strings per MPPT input : 4 Max. input current per MPP tracker : 30A Max. short-circuit current per MPP tracker : 40A Battery Input Nominal battery voltage : / Battery voltage range : 135-750V Max. charging / discharge power : 50000W Max. charging current / Max. discharging current : 100A Battery type : LFP AC Output AC voltage range / Nomlnal AC voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated AC grid frequency : 50Hz/ 60Hz Rated apparent power : 50.0kW Max. apparent power : 55.0kVA Rated grid output current (@230V) : / Max. grid output current : 83.0A AC Input Rated grid voltage : 3L/N/PE;220/380V;230/400V;240/415V Rated apparent power : 50.0kW Max. input apparent power from grid : 60.0kVA Rated input curent from grid : / Max. input current from grid : / EPS Output Nominal output voltage : 3L/N/PE;220/380V;230/400V;240/415V Nominal output frequency : 50Hz/ 60Hz Rated apparent power : 50.0kW Max. output apparent power : 55.0kVA Peak output apparent power : 60kVA | 60s Max. output current : 83.0A Max. switch time : ＜20ms Efficiency MPPT efficiency : 98.80% Euro efficiency / Max. efficiency : 98.30% Max. battery to load efficiency : / General Data Dimensions (W*H*D) (mm) : 800*620*300 Device weight : 76.0Kg Operating temperature range : -30℃~+60℃ Noise emissions (typical) : ＜50dB Standby consumption : ＜15W Degree of protection (as per lEC 60529) : IP65 Features User interface : OLED&LED&APP Communication with BMS : / Communication with meter : / Communication with portal : / Other communication : / Communication : RS485/CAN/WiFi/LAN(Optional) Integrated power control / Zero export control : Integrated/Integrated Certifications : IEC 62109/EN 61000/EN 50549-1/NTS/VDE-4105/G99/G100/CEI/NRS 097/CEI 0-21/NEN Warranty : 12 years

Read more less
