Description
Online Monitoring
With WiFi module and APP control
High energy efficiency and achieving A+++ energy efficiency under EU regulations
Super low noise, sound pressure level only 38dB(A) at 2.1 meters
7 day programmable domestic hot water storage
Intelligently adjust outlet water temperature based on ambient temperature automatically
Emergency backup built in
Water pipe connection only which is easy for installation
Power Supply
- Power Supply / Refrigerant (V/Hz/Ph): 220-240/50/1-R32
Components
- Compressor Type-Quantity/System: Twin Rotary – 1
- Fan Quantity: 1
- Fan Airflow (m³/h): 3150
- Fan Rated Power (W): 45
- Noise Level (Indoor/Outdoor) (dB(A)): 44 / 53
Hydraulics
- Water Side Type: Plate Heat Exchanger
- Heat Exchanger Water Pressure Drop (kPa): 26
- Heat Exchanger Piping Connection (Inch): G1”
- Allowable Water Flow Min./Rated/Max (L/s): 0.26 / 0.43 / 0.52
Dimensions and Weight
- Net Dimension (Indoor Unit) (LxDxH) (mm): 570 x 550 x 255
- Net Dimension (Outdoor Unit) (LxDxH) (mm): 1165 x 370 x 845
- Net Weight (Indoor Unit) (Kg): 25
- Net Weight (Outdoor Unit) (Kg): 78
Performance
- Max Heating Capacity (1) (KW): 9.2
- C.O.P (1) (W/W): 4.38
- Heating Capacity Min./Max (1) (KW): 4.3 / 9.2
- Heating Power Input Min./Max (1) (W): 927 / 2097
- C.O.P Min./Max (1) (W/W): 4.38 / 4.71
- Max Heating Capacity (2) (KW): 8.6
- C.O.P (2) (W/W): 3.37
- Heating Capacity Min./Max (2) (KW): 3.9 / 8.6
- Heating Power Input Min./Max (2) (W): 1162 / 2550
- C.O.P Min./Max (2) (W/W): 3.37 / 3.58
- Max Cooling Capacity (3) (KW): 9.5
- E.E.R (3) (W/W): 4.23
- Cooling Capacity Min./Max (3) (KW): 6.7 / 9.5
- Cooling Power Input Min./Max (3) (W): 1679 / 2242
- E.E.R Min./Max (3) (W/W): 4.0 / 4.6
- Max Cooling Capacity (4) (KW): 7.2
- E.E.R (4) (W/W): 2.8
- Cooling Capacity Min./Max (4) (KW): 4.9 / 7.2
- Cooling Power Input Min./Max (4) (W): 1451 / 2366
- E.E.R Min./Max (4) (W/W): 2.8 / 3.1
Note:
- Heating condition: water inlet/outlet temperature: 30°C/35°C, Ambient temperature: DB 7°C/WB 6°C;
- Heating condition: water inlet/outlet temperature: 40°C/45°C, Ambient temperature: DB 7°C/WB 6°C;
- Cooling condition: water inlet/outlet temperature: 23°C/18°C, Ambient temperature: DB 35°C/WB 24°C;
- Cooling condition: water inlet/outlet temperature: 12°C/7°C, Ambient temperature: DB 35°C/WB 24°C;
- The specifications are subject to change without prior notice. For actual specifications of unit, please refer to the stickers on the unit.
