Description
Installation Guide - Click Here
Data Sheet - Click Here
Features high-quality blade LFP cells from leading suppliers, designed with advanced safety features at the cell level to ensure maximum reliability and peace of mind.
Features user-friendly designs such as pre-assembled wiring harnesses and quick-connect installation, simplifying the setup process and reducing installation time.
The intelligent iESS platform continuously monitors battery performance, employing both hardware and software solutions to ensure operational safety and efficiency. Automatically adjusts settings in response to weather conditions to maximise energy efficiency.
- Cell Type: LFP
- Nominal Energy: 5.12kWh
- Maximum Parallel Number: 16
- Nominal Voltage: 51.2V
- Operating Voltage Range: 43.2-57.6V
- Dimension (W*D*H) (mm): 338 * 138.5 * 600
- Weight: 46.5Kg
- Charging Temperature: From 0 to 50℃
- Discharging Temperature: From -10 to 60℃
- Depth of Discharge: 95% DoD
- Nominal Charge: 100A
- Discharge Current: 100A
- Ingress Protection Degree: IP54
- Cooling Type: Natural convection
- Humidity: ≤95%
- Communication: CAN / RS485 / WiFi / Bluetooth
- Battery Safety: IEC 62619 / CE
- Transportation Certification: UN38.3
- Warranty: 12 years
