Description
Installation Guide - Click Here
Data Sheet - Click Here
Features high-quality cells renowned for their stability, safety, and long life cycle, providing a dependable and long-lasting power source.
The intelligent battery management system provides cell-level protection, minimising maintenance costs through predictive diagnostics and optimising energy management with smart strategies.
Features a modular design with smaller volume and weight, along with quick-connect installations that eliminate extra wiring, allowing for a straightforward setup in just 15 minutes. Equipped with a touchscreen display for real-time battery status monitoring and allows for basic settings adjustments, enhancing user interaction and control.
- Cell Type: Blade LFP
- Module Capacity: 9.4kWh
- Module Weight: 72Kg
- Nominal Voltage per module: 51.5V
- Module Dimension (W*D*H): 780*432*160 mm
- Controller Box Dimension (W*D*H): 780*432*240 mm
- Controller Box Weight: 23.8Kg
- Charging Temperature: From 0℃ to 50℃
- Discharging Temperature: From -20℃ to 60℃
- Depth of Discharge: 95%
- Nominal Charge/Discharge Current: 100A
- Max. Charge/Discharge Current: 100A
- Cycle Life: >6000 cycles at 25℃
- Ingress Protection Level: IP65
- Cooling Type: Natural convection
- Humidity: 5%~95%
- Altitude: <2000 meters
- Communication: CAN / RS485 / WiFi / Bluetooth
- Battery Safety: IEC 62619 / IEC 62477 / CE
- Transportation Certification: UN38.3
- Warranty: 12 years
